HJ Double Cone Mixer
Description
HJ double cone mixer and V type mixer machine are functionally similar. Double cone blender transports the powder or granular materials to the double cone container by vacuum or artificial means. With the constant rotation of the container, materials in it make complex motion to achieve uniform mixing.
Application
Double cone mixer is suitable for powder and granular materials mixing in pharmaceutical, chemical, food, dyes and building material industries.
Features
1.Double cone blender is energy saving, simple in operation, low labor intensity and high work efficiency.
2.The barrel of double cone mixer is made up of stainless materials. It is beautifully shaped and both inside and outside of barrel is polished.
3.An inside stirring machine can add to double cone blender, which makes it better break easy-caking materials and further strengthens the mixing effect.
4.Spray devices can be added to the double cone mixer to color the materials and increase flavors.
5.Double cone blender is remarkably effective when it comes to powder or granules with good mobility.
Parameters of Double Cone Mixer
Model | W-300 | W-500 | W-1000 | W-1500 | W-2500 | W-4000 | W-6000 | W-8000 |
Production Capacity (kg/batch) |
150 | 250 | 500 | 750 | 1250 | 2000 | 3000 | 4000 |
Overall Volume (m3) |
0.3 | 0.5 | 1 | 1.5 | 2.5 | 4 | 6 | 8 |
Mixing Time (min) |
4-8 | 4-8 | 6-12 | 6-12 | 6-12 | 6-15 | 6-15 | 6-15 |
Motor Power (Kw) |
1.1 | 2.2 | 3 | 4 | 5.5 | 7.5 | 11 | 15 |
Cylinder Speed (rolling/min) |
15 | 15 | 12 | 12 | 12 | 10 | 10 | 10 |
Overall Dimensions (L × W × H) |
1680 × 650 × 1600 |
2080 × 750 × 1900 |
2150 × 850 × 2100 |
2300 × 1600 × 3100 |
2500 × 100 × 2450 | 2980 × 1580 × 2800 |
3500 × 1800 × 3000 |
3980 × 2000 × 3200 |
Mixer Weight (kg) |
310 | 550 | 800 | 950 | 1650 | 1880 | 2350 | 2680 |
Founded in August, 2000, Lantoky Drying Engineering is a professional double cone mixer manufacturer in China. We implement strict quality control system to guarantee the performance of double cone blender. The quality of mixer machine is repeatedly checked during each stage of production. Additionally, double cone mixer as well as other machines must undergo a trial run in the workshop, and only those qualified products are allowed to leave our factory.
